Laminar Flow Glovebox Isolator

Germfree’s Compounding Aseptic Containment Isolators use HEPA (High Efficiency Particulate Air) filters to provide the highest level of operator and product protection. The supply HEPA filter provides laminar flow air, which bathes the entire work area. The exhaust HEPA filter handles all air exiting the LFGI. Additionally, two HEPA filters located inside the HEPA Purge Airlock filter the purged air. All filters are rated to remove particulates and aerosols 0.3 micron in size with a minimum efficiency of 99.99%. Particles that are smaller or larger than 0.3 micron are filtered at a greater efficiency.

Dimensions

Specifications

Features

CACI

Safety

Overall Dimensions:

  • LFGI-3USP: 54″ wide (39″ wide at base) – 32″ deep – 80″ high
  • LFGI-4USP: 66″ wide (50″ wide at base) – 32″ deep – 80″ high
  • LFGI-6USP: 90″ wide (74″ wide at base) – 32″ deep – 80″ high

Work Area Dimensions:

  • LFGI-3USP: 34 1/2″ wide – 24 1/2″ deep – 29″ high
  • LFGI-4USP: 46 1/2″ wide – 24 1/2″ deep – 29″ high
  • LFGI-6USP: 70 1/2″ wide – 24 1/2″ deep – 29″ high

Compounding Aseptic Containment Isolator Specifications
Germfree's LFGI Series: Laminar Flow Compounding Aseptic Containment Isolators

Antechamber

  • Sealed two-door airlock (16″ wide x 13 ½” deep x 14 ¼” high) maintains complete environmental separation between work area and ambient conditions.
  • HEPA-filtered Purge System: Cross contamination between the unit’s work area and the room is eliminated by purging the airlock with HEPA-filtered air. This is critical for material ingress and egress.

Waste Removal

  • Trash Tube: 4″ diameter tube, flanged for waste bag/container connection. Provided with an easily removable seal/stopper to maintain work area containment. (Stainless steel trash can is available.)
  • Sharps Tube: Straight 2 ½” diameter tube to facilitate quick drop of the largest syringes. Provided with an easily removable seal/stopper to maintain work area containment.
  • Sharps Container Shelf: Fully adjustable; accommodates most commercially available wide-mouth or hinged-top sharps collectors. (Examples: BD Part # 305610 and 305491)

Safety

  • Lock-out handle requiring key for access to work area.
  • Digital pressure readout with low pressure alarm for work area.
  • Inward/Outward Face Velocity is 95-100 linear feet per minute at gloveport opening to protect operator and product in the event of a breach of containment.
  • Glove changes can be made without breaking containment.
  • Locking casters are standard. Seismic anchors are available.

Ergonomics for the Compounding Aseptic Containment Isolator

  • Hydraulic-assist, height-adjusting stand offers a full 10″ range variance allowing operators to sit or stand comfortably for extended time periods.
  • Stainless steel sliding tray inside the airlock pulls into the work area, eliminating reaching strains.
  • Two part sleeve/glove system allows the use of most types and sizes of commercially available gloves for better dexterity and tactility.
  • Extra large oval gloveports are placed at an ergonomically correct angle to accommodate a wide range of body types and increase range of movement.
  • Gloveports have a 3″ arm rest to facilitate operator comfort and reduce fatigue.
  • Large viewing panel is set at an angle to minimize glare and enhance operator comfort.
  • Integrated foot rest

Configuration Options

Compliant with USP 797, USP 800 and Validated to CETA CAG-002-2006 Performance Standards

Compounding Aseptic Containment Isolator

  • Positive or Negative Pressure Operation: The unit’s overall work area pressure can be either positive or negative and may also be adjusted by a certifier when the unit is in place.
  • Antechamber can be set for left or right-handed operators or can be installed for use on both sides.
  • Waste and sharps removal tubes can be set for left or right-handed operators or can be installed for use on both sides.
  • Three available exhaust options can be factory-set or changed by a certifier when the unit is in-place.

Filtration

  • Full framed, standard-size Minipleat HEPA Filters: 100% of inlet and exhaust air is filtered from both the work area and the antechamber to provide a fully contained environment.
  • HEPA filters are full coverage and front-loading for easy replacement by a certifier.
  • Pre-filter extends life of work area supply HEPA filter. Can be replaced without tools.

Electrical

  • High capacity motor/blower system with speed control to extend life of HEPA filters.
  • Ten foot hospital grade power cord with molded grounded plug.
  • Sealed outlet in work area.
  • Separate, lighted, power ON/OFF indicator switches for blower and lighting.
  • High efficiency, standard sized fluorescent lights are externally mounted to minimize heat build-up.
  • Voltage = 115 Volt, 60 Hz (220/50-60 Hz also available)
  • Amperage Rating = 15
  • Running Amperage = 6 (LFGI-3 and 4USP) = 7 (LFGI-6USP)

Exhaust

  • Clean air plenum is external to the work area of the Compounding Aseptic Containment Isolator.
  • Constructed to allow for optional outside venting of exhaust air.
  • Constructed to allow for 3 exhaust options that can be factory set, or changed by a certifier in place.
  • Venting is not required for operation but is optional.

The LFGI Compounding Aseptic Containment Isolator provides personnel and product protection from particulates, dust, powders and aerosols. Microbiological particulates and aerosols, with the possible exception of prions, are also removed. Operator and product protection from gas and fumes are NOT provided by HEPA filtration, but limited protection from gas and fumes can be provided by venting or ducting. In accordance with the NIOSH alert on the handling of hazardous drugs, the LFGI can be configured for no recirculation and total exhaust of all air exiting the work area. Germfree’s Compounding Aseptic Containment Isolators are designed to meet all USP 797 guidelines for sterile compounding, as well as the regulations for handling hazardous drugs according to USP Chapter 800.

Germfree’s Compounding Aseptic Containment Isolators are constructed of high quality all welded stainless steel with a pharmaceutical grade finish. The unit incorporates an integrated height-adjustable stand with locking cleanroom grade casters. The ergonomic, stainless steel sliding tray inside the airlock is designed to eliminate reaching strains. Further, the stainless steel interior work area trays are removable and are designed to slide over one another. This facilitates easy cleanup under the work deck. The extra large oval gloveports incorporate a two-part sleeve/glove system that allows for use of most types and sizes of commercially available gloves. Glove changes can be made while maintaining containment, to enhance personnel protection.

The fluorescent light housing of the Compounding Aseptic Containment Isolator is externally mounted to provide optimum lighting in the work area. The Acrylic viewing panel is encased in a stainless steel frame and set at an angle to reduce glare and enhance operator comfort. The LFGI’s system for waste and sharps removal has seals to maintain work area containment. A fully adjustable shelf is included to accommodate most commercially available wide-mouth or hinged-top sharps collectors.

USP 797 provided the first official and enforceable requirements for preparing CSPs -Compound Sterile Preparations. USP 797 is the U.S. Pharmacopeia’s (USP) General Chapter ‘797 for Pharmaceutical Compounding Sterile Preparations’. According to the organization these requirements set “practice standards to help ensure that compounded sterile preparations are of high quality”. Chapter fundamentally changed the way that facilities that prepare compounded sterile preparations approach their work.

  • Lock-out handle requiring key for access to work area.
  • Digital pressure readout with low pressure alarm for work area.
  • Inward/Outward Face Velocity is 95-100 linear feet per minute at gloveport opening to protect operator and product in the event of a breach of containment.
  • Glove changes can be made without breaking containment.
  • Locking casters are standard. Seismic anchors are available.
