Full Range of Cleanroom Components

A twin cartridge, equal mix, high strength aliphatic urethane adhesive that bonds, seals, and finishes composite panel joints and coving in a single application, touch dry in 12 hours and fully cured in 72.

• Pristine white or translucent, colorfast and non yellowing
• Chemically neutral, non-porous, high gloss, odor free
• Non sag on vertical surfaces, low shrinkage
• Impermeable with a perm rate of 0.002 g/m²/hour (versus silicone’s 1.000), resisting moisture, mildew, fungus, and vermin
• No VOCs detected, compliant with ABSL-3, BSL-3, BSL-3Ag, BSL-4, and seismic categories A through F

A twin tube methacrylate adhesive, amber in color, non sag on vertical surfaces, and fully cured in 4 hours.

• Gap filling capacity of 0.25 inch (6mm), low shrinkage
• No VOCs detected, compliant with ABSL-3, BSL-3, BSL-3Ag, BSL-4, and seismic categories A through F

A-2020 works in combination with A-1010 Bio-Seal: A-2020 bonds materials first, and once cured, Bio-Seal seals and finishes the joint, seam, or penetration. Its adhesion strength also allows devices and MEPs to attach directly to the barrier without fasteners, and it’s impermeable, vermin resistant, and certified for CL-3, CL-4, PC3, PC4, BSL-3, and BSL-4.

Arcoform box covers, bulkheads, fascias, and utility chases assemble like a kit, with the cage frame mechanically fastened together and no brackets, external fasteners, or auxiliary attachments needed. A small, experienced crew can install or retrofit even complex designs with no specialized tools, welding, or painting required, and A-1010 Bio-Seal joins and finishes shrouds and third party components, with any damage repairable using the Arcoplast GC repair kit.

• Building code, USDA, and FDA compliant, with strong impact resistance
• Pristine White or most PMS colors, colorfast, antimicrobial, and chemical resilient
• Ultra smooth GelCoat surface, repairable on site, back to new
• Cleaned with chlorine dioxide, formaldehyde gas, or hydrogen peroxide vapor

Face plates are made from Acryloyl, offered as off the shelf options or built to custom requirements, in two formats: solid, one piece plates available in rings, caps, squares, rectangles, and ovals, or PuzzleLock, two piece interlocking plates designed to fit around MEPs and fixtures. Both formats support nearly unlimited shapes and sizes, up to 5 by 12 feet (1524 by 3600 mm).

• Compliant with ABSL-3, BSL-3, BSL-3Ag, BSL-4, and seismic categories A through F
• No VOCs detected, chemically neutral, LBC 4.0 certified
• White or most PMS colors, sealed and finished with A-1010 Bio-Seal
• Cleaned with chlorine dioxide, formaldehyde gas, hydrogen peroxide vapor, squeegee wipe down, or water spray hose wash down

Arcoform box covers, bulkheads, fascias, and utility chases assemble like a kit, with the cage frame mechanically fastened together and no brackets, external fasteners, or auxiliary attachments needed. A small, experienced crew can install or retrofit even complex designs with no specialized tools, welding, or painting required, and A-1010 Bio-Seal joins and finishes shrouds and third party components, with any damage repairable using the Arcoplast GC repair kit.

The Arcoplast flush glazed window offers single or double glazing in a range of thicknesses and glass types. The anodized aluminum frame fits standard 3 5/8 or 6 inch metal stud framing and comes ready to install, integrating seamlessly into the primary barrier for a flush, cGMP compliant finish rated to sustain 20 minutes at 3000 pascal.

• Aseptic finish, air, moisture, and gas tight
• Meets FDA 21 CFR and related regulatory requirements
• Resistant to fungi and bacteria

Fiberglass reinforced window frames fit new and existing construction, spanning wall thicknesses from 3 to 10 inches, with a rubber gasket vision panel and a smooth, high gloss GelCoat finish.

• Glazed with glass or acrylic, built for wet areas
• Resistant to oxidation and corrosion
• Custom dimensions available

Fiberglass strands give the pultruded window profile high tensile strength, with Class A fire rated resins and a smooth, stain resistant surface built for demanding conditions. Mitered corners reinforced with galvanized brackets keep the lightweight assembly quick and easy to install.

• Double wall construction with an integrated rubber gasket frame
• High gloss, weatherable ABS trim
• Resistant to chemicals, stains, water, moisture, and high saline conditions
• Resists mildew, fungus, and microbial activity, well suited to food and beverage or corrosive cleanroom environments
• Long service life with no rejuvenating maintenance required

• Molded-in high-gloss weather able-capped ABS plastic
• Orc as® stainless steel slam latch

VLADS doors are made to measure and factory assembled to customer specifications, hung on a concealed, nickel plated, self-closing hinge with 175 degrees of motion for unhindered access to cabling, decon ports, air filters, and hardware. LDUs, monitoring sensors, and gauge cutouts are all factory cut with a precision CNC router, keeping on-site tooling to a minimum for a quick, easy installation.

• Solves cable management by providing easy access to the entire cable feed
• Allows outdated monitoring systems or malfunctioning sensors to be replaced without compromising the barrier
• Can be quickly repurposed to meet new or urgent research needs
